12V 200Ah Lithium Battery

Cell specification : LiFePO4-32700- 6.0Ah, 4S34P.

Model: BL12200-GA

Rated Capacity  102Ah      Standard discharge after standard charge

Nominal Voltage              12.8V     Operating voltage

Charge Method CC/CV   Constant current, constant voltage

Charge Voltage  14.6V

Discharge Cut-off Voltage             10.0V     Voltage at end of discharge

Recommended Charge Current   40A – 60A

Max Continuous Discharge Current           200A

Pulse Discharge Current            400A      <5S

Weight (approx.)              59.53 Lbs (27 kg)

Battery Dimension (L×W×H）     20.55” x 9.45” x 8.58” (522*240*218mm)

Operation Temperature Range:

Charge  32F～113F  (0～45℃)

Discharge -4F～140F (-20～60℃)

12V 200Ah Lithium Battery Datasheet
